Expert 220 Pro
Free delivery - Shipped within: 20 working days
Free returns and exchanges
All the promises of an Expert Pro system.
Utter connectivity for the most demanding audiophiles. The Expert 220 Pro embeds the full set of Devialet technologies, as well as an ultra-configurable phono stage, designed for vinyl enthusiasts.
Specifications
Range
StereoExclusive technologies
ADH®, SAM®, RAM®, EVO®, DAC Magic Wire®streaming services
Roon ReadyUPnP
Airplay®
Spotify Connect
Daisy chaining
Up to 8 unitsPhono stage
Standard (MM / MC)Pre-amplified output
Optional (on order)Casing
Carved out from a single aluminium blockSide plating
NoPower Supply
Universal 90-240Vac – 50/60HzPower cable provided adapted to the country
Patented single stage switching mode topology
High power level: 600W continuous, 4000W peak
High output with power factor correction
Dimensions & Weights
Dimension
Width: 383mm | Depth: 383mm | Height: 40mmWeight
5.9KgConnectivity
wi-fi
2.4GHz / 5GHz 802.11ac, compatible with 802.11a/b/g/nEthernet
RJ45 100/1000 Mbpsusb
USB Audio 2.0 AsynchronousVery low latency
Bi-directionality (for digitisation of the analog sources)
Digital coaxial inputs
Up to 4x RCA 75ΩDigital optical inputs
1x TOSLINKUp to 1x miniTOSLINK 3.5mm
Supported formats
Up to 32bits / 192kHz PCM (USB)Up to 24bits / 192kHz PCM (Roon Ready, UPnP, AES/EBU, Coaxial)
Up to 24bits / 96kHz PCM (Optical)
Up to 1bit / 3.072000MHz DSD64 (USB, Coaxial)
Analog inputs
Up to 2x RCA stereoSensitivity adjustable via the Configurator
Advanced phono stage (MM / MC)
Speaker output
4mm banana plugs, fork connectors or stripped cablesCompatible with all speakers from 8Ω to 2Ω
Short-circuit protection
Active filtering available
Home automation
Up to 1x RS232 3.5mm 115200 bauds (documentation available via the Configurator)Trigger
3.5mm trigger connector Trig In and Trig OutPerformances
power
2x220 Watts RMS under 6ΩDistortion at full power
0.0005% THD+NDistortion at full power
0,00025% (10W / 6Ω)Distortion at 10w
0.00025% THD+NDistortion at 10V
0,0005% THD+NSignal-to-noise ratio
130dBOutput impedance
0.001ΩDamping factor
8000Bandwidth
DC-30kHz @ -0.1dBDC-95kHz @ -3dB
Phase rotation
0.4° at 20kHz1.8° at 40kHz
Thermal distorsion
Below measurement thresholdWhat's in the box
- 1 Devialet Expert 220 Pro
- 1 Expert Remotes (2x3 AAA batteries LR03 1,5V included)
- 1 User Manual
- 1 Warranty booklet (2 years)
- 1 SD card
- 1 Power cable
- 1 Pair of gloves
- 1 Microfibre cloth
FAQ
Expert Pro systems come with a 2-year warranty. Effective from date of purchase.
No, the Pre-Out board needs to be installed at our factory and therefore can only be purchased on initial order.
Our engineers have managed to increase the efficiency of the Class D board of the 140 Pro in order to get 10W extra power in stereo, and have been working hard in porting and adapting the dual-mono bridged mode from the 220 Pro and 250 Pro onto the 140 Pro, in order to deliver 210W in dual-mono with the same harmonic distorsion and signal-to-noise ratio than the 220 Pro and 250 Pro.
